Move / Transport Drum
Drum Handling
drum handling-F11
drum handling-U2
Multi-Function Truck
Drum Truck
Model
F11
U2
Capacity
250 kgs / 550 lb
250 kgs / 550 lb
Weight
¡@
¡@
Dimension
¡@
¡@

Drum Carrier
drum carrier-F12drum carrierdrum carrierdrum carrier
Drum Truck / Drum Caddy
Model
F12
Capacity
300 kgs / 660 lb
Weight
21.6kgs / 47.52 lb
Dimension
¡@

Drum Lifter
drum lifterdrum stacker¡@
Electric Mobile Forklift / Stacker

Model
DFT-1000
Capacity
300kgs¡@
Weight
290kgs¡@
Dimension
¡@


Move / Transport, Mix, Drain
Drum Handling

drum handling-F16drum handlingdrum handlingdrum handlingdrum handling

drum handler
move, transport drum
mix drum content
drain, dispense
weight
Magic Carrier
Model
F16
Feature


Lift, move, tilt, agitate, and drain heavy drums! Innovative static and dynamic design with safety features to handle heavy drums easily.

*Lift the drum easily according to leverage principle (pulling down the handle to raise the drum 12-29cm
above the earth)
*Do not pull the clutches of both sides of the drum body when pulling down the handle, but on the contrary, it needs to pull them while loosening the handle.
*Roll the magic-carrier forward and push the saddle into the center of the drum.
*Can adjust height freely
*360° rotation makes the materials mix uniformity secured the extra strength cinch chain to the front of the drum with the improved rachet tightener. No tools are needed.
*Can tilt and fix the tank body in diverse angle.

Capacity
350kgs / 770 lb
Weight
47kgs / 103.4 lb
Dimension
90 x 20 x 107 cm


Lifting / Roller
¡@
Pneumatic lift / Lower
Mixing
Dispensing
Pneumatic lift / Lower
Manual rotate for mixing / dispensing
Completely Pneumatic Opration
Mixing
Dispensing
Model
TH-200H
TH-200
Capacity
350 kg
Working Pressure
5 ~ 7 bar
Clearence after lifting
1350 mm
Clearence when dispensing
1480 mm
Weight
220 kg
Dimention
1250 x 950 x 2100 mm

Move / Transport, On-Off Pallet, Drain
Drum Carrier
drum carrier-F28¡@ drum carrierdrum carrier
drum carrierdrum carrier

Stainless Steel Multi-Function Carrier

1. Made of 304 stainless steel
2. Washable & resistant to corrosion
3. Suitable for food and pharmaceutical application



Multi-Function Carrier
Multi-Function Carrier
Stainless Steeel Multi-Function Carrier
Model
F28
F28S
Feature
*Four 20cm wheels with roller bearing roll efficiently, track straight, steer easily.
*U-shapped handles keeps knuckles inside protecting from harms.
*Extra handle length gives more leverage while loading and moving heavy drums.
*Frame shape provides convenient dispensing position.
*Freely-hoist-and-contract hook can easily set up the supporting point.
*Max. Load: 454kg (1000LB). Users should be responsible for safety if solvent is dangerous in the drum.
*Toe prongs are in accordance with human mechanics, angle accurate and precise.
*Can pass the aisle easily
*Can be oblique, can be operated by one people
*50 gallons truck, wood trunk, paper trunk, skep are all available.

Capacity
450kgs / 990 lb
kgs / lb
Weight
37kgs / 81.4 lb
kgs / lb
Dimension

¡@

Drum Lifter
Automatic fork truck double drum lifter constructed of welded steel featuring automatic operation allows one person to secure, move, and release drums from fork truck seat.
Drum lifter
drum carrier-STC

drum carrier-DTCSdrum carrier
featuring smooth handling while transporting

Fork Truck Double Drum Lifter
Fork Truck Single Drum Lifter
Automatic Fork Truck Double Drum Lifter with shock absorbers
Fork Truck Double Drum Lifter
Model
STC
DTCS
DTC
Capacity
250 kgs / 550 lb
500 kgs / 1100 lb
500 kgs / 1100 lb
Weight
¡@
  ¡@
Dimension
¡@
  ¡@

Drum Lifter
¡@
drum lifter
drum lifter
drum lifter
An Inexpensive alternative to mechanical drum lifters
Horizontal Lifting
Oblique Lifting

Speedy Lifting Hook
Model
F10
Capacity
300 kgs
Weight
¡@
Dimension
¡@

Drum Lifter
¡@ drum lifter 100 literslift drum
For 100 Liters
¡@ drum lifter for 200 liters drum
For plastic, steel and fiber drums with top lip
For 200 Liters

Model
F8
F9
Capacity
¡@
¡@
Weight
¡@
¡@
Dimension
¡@
¡@


Drum Stand / Drum Frame
Easy Lifting Frame
One-man Tilter
Suitable: 200 Liter drum
Drum stand with handle for easy handling by one person
Two-man TilterTwo-man Tilter
Suitable: 200 Liter drum
Drum stand
Suitable: 20 Liter drum
Drum Cradle / Can Tilter
Suitable: 20 Liter can
Prevent accidents and spilling mess
Drum Cradle / Can Tilter
Model
T-FV-1
T-FV
T-FV-20
T-5D
Max. Load
¡@
¡@
¡@
¡@
Weight
12.5 kg
12 kg
14 kg
6.5 kg
Dimension
¡@
¡@
  ¡@

Dolly
Drum Dolly
Drum dolly¡@
Dolly¡@
Dolly (50 Gallons)
Dolly (25 Gallons)
Model
DD-1
DD-2
Max. Load
¡@
¡@
Weight
¡@
¡@
Dimension
¡@
¡@

Drum Dolly
Dolly¡@
¡@Drum dolly
Dolly (50 Gallons)
Dolly (25 Gallons)
Model
DC-1
DC-2
Max. Load
¡@
¡@
Weight
¡@
¡@
Dimension
¡@
¡@


F28 Multipurpose
Phantom Truck

Move on / off pallet, dispense drum

Weight:
Max. drum wight:






F12 Drum Truck

Weight:
21.6kg
dimension:
79*28*66 cm
For 20~200 liter drum

Max. capacity: 250kg



F16 Magic Carrier
Move, rotate/mix, pour/dispense heavy drums with ease

Weight: 46.3kg
dimension: 90*20*107cm
Suitable for: Max.250kg drums,200L drums
