FEATURES
High Start Torque
Instantly Reversible
Stalling Safety
Positive Start
Rugged Design
Intrinsically safe in hazardous environment (ex. mines, petrochecmical, volatilve atmosphere)
Mounting Flexibility: Flange / Foot / Hub / IEC / NEMA / Custom Mounting Available
Modular Design: All motors may be equipped with gear reducer, brake, hand, remote pendant contro as options.
Air Motors can easily operate under conditions which are unfavorable for electric, hydraulic, stepper and servo motors. |
 |
 |
 |
M13S |
M14 |
M15 |
 |
 |
 |
M16 |
M17 |
M18 |
Series |
Maximum Output |
Max. Speed |
Mass |
|||||||
Power |
Speed |
Torque |
Air Consumption |
|||||||
kW |
HP |
RPM |
Nm |
ft-lb |
l/min |
CFM |
kg |
lb |
||
M13S (110) |
1.36 |
1.82 |
2000 |
6.5 |
4.8 |
1680 |
59 |
2400 |
13 |
28.6 |
M14 (210) |
2.8 |
3.7 |
1950 |
14 |
10.3 |
4680 |
165 |
2400 |
26 |
57.2 |
M15 (310) |
6.2 |
8.3 |
1800 |
33 |
24.3 |
7925 |
280 |
2400 |
48 |
105.6 |
M16 (410) |
10.8 |
14.5 |
1600 |
65 |
48 |
12000 |
424 |
2000 |
62 |
136.4 |
M17 (510) |
16.2 |
21.7 |
1100 |
140 |
103.3 |
19810 |
700 |
1500 |
125 |
275 |
M18 (610) |
23.3 |
31.2 |
1500 |
150 |
110.6 |
22500 |
900 |
2000 |
125 |
275 |
Working Fluid: Compressed Air¡@¡@Operating Pressure: 6 kg/cm^2¡@¡@Max. Operating Pressure: 7 kg/cm^2¡@¡@¡@
Ambient Temperature: -10 ~ +120°C
Ordering Code
| AIR GEARMOTORS For applications where precise and variable turning power and speed is a requirement. Examples are bolt tensioning equipment or rock drilling rigs, precise lifting, lowering, traversing or turning. Unlike electric gearmotors, no chance of burn-out nor heat buildup with TONSON Air Motors. Direction of rotation is instantly reversible. Precise Turning Power, High Torque Capacity |
 |
| BRAKES For applications where positive braking is a requirement, a range of caliper brakes is offered. These are designed to withstand full stall torque of the air motor. The brake consists of two spring applied shoes pressed against a central hub. The shoes are released by applying air pressure to the cylinder/piston assembly. The brake torque can be varied by adjustment of two spring adjusters but it is normally set so that a pilot pressure of 4 bar (60 PSI) will fully release it. |
 |
| Valve Options (1/2", 3/4", 1", 1 1/4", 1 1/2", 2") A range of bolt on Hand Control Valves and Remote Control Valves are available for use on all TONSON Piston Air Motors. Designed to completely eliminate all static friction, thereby reducing hysteresis effect and offering a very high degree of sensitive speed control. Suitable for applications where forward and reverse hand control is required, with spring centre to neutral position by a lever mechanism or controlled by air pilot signal.. Two control styles are manufactured: i) Equal power and speed in both directions ii) Biased to give a degree of control for hoisting applications. |
 |
 |
 |
Hand Control Valve |
Custom Hand Control Valve |
Remote Control Valve |
| One pilot port, 1/4" on each end. Caps may be positioned with port at top, bottom or either side. The pilot pressure range is between 1.4 bar (20 psi) and 4.8 bar (70 psi), incresed pilot pressure gives increased speed. |
 |
 |
