Diaphragm Pumps


Description




Features
*Easy Installation
*Ease of Operation
*Ease of Maintenance
*Variety of Diaphragms available
  -Neoprene
  -NBR
  -EPDM
  -Viton
  -Teflon

Accessories
*FRL (Filter / Regulator / Lubricator)
*Surge Suppressors
*Pail & Drum Transfer Kits
*Filtration
*Trolley

By Fluid Inlet / Outlet
*3/8"
TS-60
TS-D03ATTT

*1/2"
TS-040ATTT
TS-040PTTT
TS-F040PTTT
TS-F040ATTT
TS-D040ATTT
TS-D040STTT

*3/4"
TS-D060ATTT
TS-D060STTT

*1"
TS-100ATTT
TS-100ANNN
TS-100STTT
TS-100SNNN
TS-D100ATTT
TS-D100STTT

*1 1/2"
TS-150ATTT
TS-150ANNN
TS-150STTT
TS-150SNNN
TS-D150ATTT
TS-D150STTT

*2"
TS-200ATTT
TS-200ANNN
TS-200STTT
TS-200SNNN
TS-D200ATTT
TS-D200STTT

*3"
TS-300ATTT
TS-300ANNN
TS-300STTT
TS-300SNNN


By Flow Rate
*0 ~ 13 l/min
*0 ~ 40 l/min
*0 ~ 88 l/min
*0 ~248 l/min
*0 ~ 392 l/min


By Wetted Material

*Aluminum
*PP (Polypropylene)
*Stainless Steel

3/8"
diaphragm pump
  pump
pump with mixer
Model
TS-60-3
TS-D03ATTT
TS-60-3-V
TB-M1-3/8
Material
Aluminum
Aluminum
Aluminum
Aluminum
Flow Rate (L/min | gpm)
13 | 3.4
36 | 9.5
13 | 3.4
13 | 3.4
Fluid Inlet / Outlet (PT)
3/8"PT
3/8"PT
3/8"PT
3/8"PT
Air Inlet (PT)
1/4"PT
1/4"PT
1/4"PT
1/4"PT
Suction Lift (m)
6
6
6
6
Shipping Weight (kg)
5
5
5
5

Shipping Dimensions
(L x W x H)

183*141*214

PDF Download


3/8"
diaphragm pump
pump diaphragm pump pump
air spray gun
Model
TS-60-1
TS-60-9
TS-60-5
TS-60-4
TS-60-2
Material
Aluminum
Aluminum
Aluminum
Aluminum
Aluminum
Flow Rate (L/min | gpm)
13 | 3.4
56 | 14.79
13 | 3.4
13 | 3.4
13 | 3.4
Fluid Inlet / Outlet (PT)
3/8"PT
3/4"PT
3/8"PT
3/8"PT
3/8"PT
Air Inlet (PT)
1/4"PT
1/4"PT
1/4"PT
1/4"PT
1/4"PT
Suction Lift (m)
6
7.6
6
6
6
Shipping Weight (kg)
7
8.5
7
8
11

Shipping Dimensions
(L x W x H)


PDF Download



1/2"
diaphragm pump
diaphragm pump
pump
Model
TS-040ATTT
TS-040PTTT
TS-F040ATTT
TS-F040PTTT
Material
Aluminum
PP
Aluminum
PP
Flow Rate (L/min | gpm)
35 | 9.2
35 | 9.2
45 | 11.88
45 | 11.88
Fluid Inlet / Outlet (PT)
1/2"PT
1/2"PT
1/2"PT
1/2"PT
Air Inlet (PT)
1/4"PT
1/4"PT
1/4"PT
1/4"PT
Suction Lift (m)
6m
6m
6m
6m
Shipping Weight (kg)
5.5
4
5.5
4
Shipping Dimensions
(L x W x H)
195*195*208
207*195*225
205*105*207
185*155*230
PDF Download

1/2"
diaphragm pump
pump
Model
TS-D040ATTT
TS-D040STTT
Material
Aluminum
SS
Flow Rate (L/min | gpm)
48 | 12.68
48 | 12.68
Fluid Inlet / Outlet (PT)
1/2"PT
1/2"PT
Air Inlet (PT)
1/4"PT
1/4"PT
Suction Lift (m)
6m
6m
Shipping Weight (kg)
5.5
7.5
Shipping Dimensions
(L x W x H)
225*170*245
225*170*245
PDF Download

3/4"
diaphragm pump
pump
Model
TS-D060ATTT
TS-D060STTT
Material
Aluminum
SS
Flow Rate (L/min | gpm)
56 | 14.79
56 | 14.79
Fluid Inlet / Outlet (PT)
3/4"PT
3/4"PT
Air Inlet (PT)
1/4"PT
1/4"PT
Suction Lift (m)
7.6m
7.6m
Shipping Weight (kg)
5.5
7.5
Shipping Dimensions
(L x W x H)
228*170*248
228*170*248
PDF Download

1"
diaphragm pump
diaphragm pump
pump
pump
Model
TS-100ATTT
TS-100ANNN
TS-100STTT
TS-100SNNN
Material
Aluminum
Aluminum
SS
SS
Flow Rate (L/min | gpm)
80 | 21.13
80 | 21.13
80 | 21.13
80 | 21.13
Fluid Inlet / Outlet (PT)
1"PT
1"PT
1"PT
1"PT
Air Inlet (PT)
1/4"PT
1/4"PT
1/4"PT
1/4"PT
Suction Lift (m)
6m
6m
6m
6m
Shipping Weight (kg)
10
10
15
15
Shipping Dimensions
(L x W x H)
230*235*340
230*235*340
230*235*340
230*235*340
PDF Download

1"
diaphragm pump
Model
TS-D100ATTT
TS-D100STTT
Material
Aluminum
SS
Flow Rate (L/min | gpm)
180 | 47.55
180 | 47.55
Fluid Inlet / Outlet (PT)
1"PT
1"PT
Air Inlet (PT)
3/8"PT
3/8"PT
Suction Lift (m)
6m
6m
Shipping Weight (kg)
10
15
Shipping Dimensions
(L x W x H)
270*228*346
270*228*346
PDF Download

1 1 /2"
diaphragm pump
pump
diaphragm pump
pump
Model
TS-150ATTT
TS-150ANNN
TS-150STTT
TS-150SNNN
Material
Aluminum
Aluminum
SS
SS
Flow Rate (L/min | gpm)
240 | 63.4
240 | 63.4
240 | 63.4
240 | 63.4
Fluid Inlet / Outlet (PT)
11/2"PT
11/2"PT
11/2"PT
11/2"PT
Air Inlet (PT)
1/2"PT
1/2"PT
1/2"PT
1/2"PT
Suction Lift (m)
6m
6m
6m
6m
Shipping Weight (kg)
30
30
45
45
Shipping Dimensions
(L x W x H)
400*400*370
400*400*370
400*400*370
400*400*370
PDF Download

1 1 /2"
diaphragm pump
Model
TS-D150ATTT
TS-D150STTT
Material
Aluminum
SS
Flow Rate (L/min | gpm)
300 | 79.25
300 | 79.25
Fluid Inlet / Outlet (PT)
11/2"PT
11/2"PT
Air Inlet (PT)
1/2"PT
1/2"PT
Suction Lift (m)
6m
6m
Shipping Weight (kg)
30
45
Shipping Dimensions
(L x W x H)
370*266*430
440*280*470
PDF Download


2"
pump
pump
Model
TS-200ATTT
TS-200ANNN
TS-200STTT
TS-200SNNN
Material
Aluminum
Aluminum
SS
SS
Flow Rate (L/min | gpm)
390 | 103.02
390 | 103.02
390 | 103.02
390 | 103.02
Fluid Inlet / Outlet (PT)
2"PT
2"PT
2"PT
2"PT
Air Inlet (PT)
1/2"PT
1/2"PT
1/2"PT
1/2"PT
Suction Lift (m)
6m
6m
6m
6m
Shipping Weight (kg)
40
40
63
63
Shipping Dimensions
(L x W x H)
430*458*470
430*458*470
430*450*470
430*458*470
PDF Download

2"
Model
TS-D200ATTT
TS-D200STTT
Material
Aluminum
SS
Flow Rate (L/min | gpm)
580 | 153.22
580 | 153.22
Fluid Inlet / Outlet (PT)
2"PT
2"PT
Air Inlet (PT)
1/2"PT
1/2"PT
Suction Lift (m)
6m
6m
Shipping Weight (kg)
40
63
Shipping Dimensions
(L x W x H)
413*319*525
413*319*525
PDF Download

3"
diaphragm pump
diaphragm pump
diaphragm pump
pump
Model
TS-300ATTT
TS-300ANNN
TS-300STTT
TS-300SNNN
Material
Aluminum
Aluminum
SS
SS
Flow Rate (L/min | gpm)
580 | 153.22
580 | 153.22
580 | 153.22
580 | 153.22
Fluid Inlet / Outlet (PT)
3"PT
3"PT
3"PT
3"PT
Air Inlet (PT)
3/4"PT
3/4"PT
3/4"PT
3/4"PT
Suction Lift (m)
6m
6m
6m
6m
Shipping Weight (kg)
79
79
158
158
Shipping Dimensions
(L x W x H)
685*420*782
685*420*782
685*420*782
685*420*782
PDF Download

TS-1"~3"

Pneumatic Double Diaphragm Pump

TS-1/2"(DP)

Pneumatic Double Diaphragm pump

Outlet Inlet dia: 1/2"
Discharge volume: 50L/min



TS-3/8"(AA)Teflon

Pneumatic Double Diaphragm pump

Outlet Inlet dia: 3/8"
Discharge volume: 13 L/min

TS-60-1

Diaphragm Pump with Stand

Outlet Inlet dia: 3/8"

TS-60-2

Diaphragm pump with mixer

Outlet Inlet dia: 3/8"
